E2: Assembly and Electrical Installation
Checklist for Assembly and Electrical Installation of the module
Device type/equipment identification
Version: HW/FW
Date
Editor
Test engineer
Remark
No.
Requirement (optional)
Yes
Remark
1
Was assembly completed according to the specifications
(specifications form the planning phase or according to the
user manual)?
2
Are all unused ports fitted with a blanking cap?
3
Do the cable cross sections and installation correspond to the
specifications?
4
Does the connection technology correspond to the
specifications in the technical data and in the relevant user
manual?
No.
Requirement (optional)
Yes
No
Remark
5
Is the data width set correctly according to the specifications?
6
Is the profile/PROFIsafe address set correctly according to the
specifications?
Date
Signature (editor)
Date
Signature (test engineer)
E3: Startup and Parameterisation
Checklist for startup and parameterization of the module
Device type/equipment identification
Version: HW/FW
Date
Editor
Test engineer
Remark
No.
Requirement (optional)
Yes
Remark
1
Was startup completed according to the specifications
(specifications from the planning phase or according to the
user manual)?
2
During startup, is it ensured that any person intentionally
starting hazardous movements can only do so with a direct
view of the danger zone?
3
Are all parameters parameterized for the outputs & inputs and
is the F_WD_Time set correctly/
4
Are the output test pulses parameterized according to the
actuator to be connected?
No.
Requirement (optional)
Yes
No
Remark
5
Have safety distances that must be observed been calculated
according to the response and delay times implemented/
Date
Signature (editor)
Date
Signature (test engineer)
