131
Specifications
Appendix
Specifications
General
Record format HDCAM-SR (SRW-5000/5500) or
HDCAM (SRW-5500)
Power requirements
100 to 240 V AC, 50/60 Hz
Power consumption
320 W (with all option boards installed)
Peak inrush current
(1) Power ON, current probe method: 54 A (240 V),
17 A (100 V)
(2) Hot switching inrush current, measured in
accordance with European standard EN55103-1:
33 A (230 V)
Operating temperature
+5°C to +40°C (+41°F to + 104°F)
Storage temperature
–20°C to +60°C (–4°F to + 140°F)
Humidity 25% to 80% (relative humidity)
Mass 30 kg (66 lb 26 oz)
Dimensions 427 × 218 × 544 mm (w/h/d)
(16
7
/
8
× 8
5
/
8
× 21
1
/
2
inches)
Tape system
Tape speed HDCAM-SR: 94.1 mm/s (with the frame
frequency of 24 Hz)/98.1 mm/s (with
the frame frequency of 25 Hz)/117.6
mm/s (with the frame frequency of 30
Hz)
HDCAM: 96.7 mm/s (with the frame
frequency of 29.9 Hz)/80.6 mm/s (with
the frame frequency of 25 Hz)/77.4
mm/s (with the frame frequency of 24
Hz)
Digital Betacam: 96.7 mm/s
HDCAM-SR recording and playback time (using BCT-
124SRL)
155 minutes (with the frame frequency
of 24 Hz)/149 minutes (with the frame
frequency of 25 Hz)/124 minutes
(with the frame frequency of 30 Hz)
HDCAM playback time (SRW-5000; using BCT-
124HDL) / HDCAM recording and playback time
(SRW-5500; using BCT-124HDL)
155 minutes (with the frame frequency of
24 Hz)/149 minutes (with the frame
frequency of 25 Hz)/124 minutes (with
the frame frequency of 29.97 Hz)
Digital Betacam playback time (using BCT-D124L)
124 minutes
Fast forward/rewind time
Approx. 4 minutes (using BCT-124SRL)
Search speed
Shuttle mode
HDCAM-SR playback: Still to approx.
±50 times normal playback speed
(with the frame frequency of 24 Hz)
Still to approx. ±48 times normal
playback speed (with the frame
frequency of 25 Hz)
Still to approx. ±40 times normal
playback speed (with the frame
frequency of 30 Hz)
HDCAM playback: Still to approx. ±50
time normal playback speed (with the
frame frequency of 29.97 Hz)/ Still to
approx. ±58 time normal playback
speed (with the frame frequency of 25
Hz)
Digital Betacam playback: Still to
approx. ±50 times normal playback
speed
Variable mode
HDCAM-SR playback: –1 to +2 times
normal playback speed
HDCAM playback: –1 to + 2 time normal
playback speed
Digital Betacam playback: Still to
approx. –1 to +3 time normal playback
speed
Jog mode HDCAM-SR playback: Still to ±2 times
normal playback speed
HDCAM playback: Still to ±3 times
normal playback speed
Digital Betacam playback: Still to ±3
times normal playback speed
Dynamic Tracking range
–1 to +2 times normal playback speed
Load/unload time
7 seconds or less
Recommended tapes
HDCAM-SR cassette (S, L):
BCT-6SR/22SR/40SR
BCT-64SRL/94SRL/124SRL
HDCAM cassette (S, L):
BCT-6HD/12HD/22HD/40HD
BCT-34HDL/64HDL/124HDL
Digital Betacam cassettes (S, L)
(for playback only)
Digital video system
Digital video signal format
Sampling frequency
Y: 74.25 MHz
P
B
/P
R
: 37.125 MHz
RGB: 74.25 MHz
Quantization 10 bits/sample
Compression MPEG-4 Studio Profile
