Appendix

Items Relating to the Audio Control (Nos. 807 to ...)

Item number Item Setting Function

807 AUDIO MONITOR-L

select

Selects the audio channel output from the MONITOR

OUTPUT L connector.

Sub items

A-MON CH1 disable

[enable]

A-MON CH2 [disable]

enable

A-MON CH3 [disable]

enable

A-MON CH4 [disable]

enable

A-MON CH5 [disable]

enable

A-MON CH6 [disable]

enable

A-MON CH7 [disable]

enable

A-MON CH8 [disable]

enable

A-MON CH9 [disable]

enable

A-MON CH10 [disable]

enable

A-MON CH11 [disable]

enable

A-MON CH12 [disable]

enable

Default Chapter2
- Important Safety Instructions2
- Table of Contents4
Chapter 1 Overview9
Features9
- Features of the SRW-5000/SRW-55009
- Features of the Control Panel11
Optional Accessories13
Using the CD-ROM Manual13
- CD-ROM System Requirements13
- Preparations13
- To Read the CD-ROM Manual13
Chapter 2 Locations and Functions of Parts15
Control Panel15
- Upper Control Panel16
- Power Switch16
- Error Indicator16
- Lower Control Panel17
- Phones Jack17
- Monitor R Buttons17
- Set Button19
- Play Button20
- Tape Transport Control Section20
- Servo Indicator22
- Rec Inhibit Indicator22
- System Set-Up Panel23
Connector Panel24
- Power Supply28
Chapter 3 Setting up the VTR29
Connecting External Equipment29
- Making HD Digital Connections29
- Making NTSC/PAL Digital Connections30
- Cascade Connection31
Reference Signals32
- Reference Signals for Output Video32
- Reference Signal Connections33
Handling Cassettes34
- Recommended Cassettes34
- Inserting and Ejecting Cassettes34
- Preventing Accidental Erasure35
Using a Memory Stick35
- Notes on Memory Stick35
- Ejecting the Cassette35
Chapter 4 Menu Settings37
Registering and Storing Menu Settings37
- Menu Configuration37
- Changing Menu Settings37
- Registering Items to the VTR SETUP Menu38
- VTR Memory Bank Function39
- Memory Stick Operations41
- Adding Titles to the Data46
- Details on VTR Memory Bank and Memory Stick Functions46
- Memory Stick Data Compatibility47
- Automatic Reading from a VTR Bank at Power on47
- Saving and Recalling DEFAULT Settings on a Bank47
- Saving and Recalling DEFAULT Settings in a "Memory48
- Stick48
HOME Menu50
- Selecting the Output Signals (PB/EE)51
- Record Inhibit Mode (REC INH)51
- Selecting the Edit Mode and Edit Channel51
  - INS TC, ins VIDEO, ins AUDIO and ins CUE)51
- Preread Settings (PRE READ)52
- Still-Picture Output (FREEZE)52
- Setting the Preroll Time (PREROLL TIME)52
- Selecting DMC Playback (DMC)52
- Setting the Stop Code (STOP CODE)53
TC Menu56
- Setting the Time Data (TIMER SEL/RESET/SET/HOLD)57
- Setting the Time Code Reader (TCR SEL)60
- Setting the Time Code Generator (TCG SOURCE/MODE)60
- Selecting the Time Code Running Mode (RUN MODE)60
- Selecting the Drop Frame Mode (DF/NDF)61
- Selecting the Content of the Second Time Code Display61
  - Area (TC2 SEL)61
- Selecting CTL Display Mode (TAPE TIMER)61
- Presetting Pulldown Time Code (PDPSET MENU)61
  - (When HKSR-5001 Is Installed)61
  - (Tcconv Menu)62
- Displaying the Pulldown Time Code (PDTC DISP) (When HKSR-5001 Is Installed)64
- Superimposition of Character Information64
  - Chara Super/H-Pos/V-Pos)64
CUE Menu68
- Selecting a Multi-Cue Mode69
- Registering Cue Points69
- Erasing Cue Point Data71
- Prerolling to a Cue Point71
- Changing a Cue Point into an Edit Point72
- Backspace Editing72
- TELE FILE Menu72
VIDEO Menu87
- Selecting the Reference Signal (SERVO REF)88
- Adjusting the Output Video Signal (MASTER to FINE)88
AUDIO Menu91
- Selecting the Audio Input Signal (AUDIO IN)92
- Digital Audio Output Signal Source Track Selection (DIGOUT EXCHNG)92
- Analog Audio Output Signal Source Track Selection93
  - (Anaout Exchng)93
- Digital Audio Output Signal Source Track Selection93
  - (Sdout Exchng)93
- Audio Transition Type Selection for Digital Audio Editing94
  - (Audio Edit)94
- Fade Processing Time Selection for Digital Audio Editing94
  - (Fade Time)94
  - Replace)95
- External Device Analog Audio Edit Preset Command Replace Mode Selection (ANALOG AUDIO EDIT REPLACE)95
- Replace Mode Selection (ANALOG AUDIO EDIT REPLACE)95
- PITCH GROUP Selection95
  - Group Select)95
SET up Menu97
- VTR SETUP Menu98
- PANEL SETUP Menu100
Chapter 5 Recording/Playback102
Preparing for Recording102
- Setting Switches and Menus102
- Selecting Audio Signals103
- Adjusting the Recording Level104
  - Signals Being Recorded105
- Audio Level Meter Display Modes105
Recording106
Preparing for Playback107
- Setting Switches and Menus107
- Adjusting the Audio Playback Level107
- Selecting the HD-SD Conversion Mode108
Playback109
- Normal-Speed Playback109
- Variable Speed Playback109
- Variable Mode Playback110
- Shuttle Mode Playback110
- Capstan Override Playback111
- DMC Playback111
- Playing Back Non-Audio Data112
- Performing Program Play113
Chapter 6 Editing115
Basic Automatic Editing115
- Overview of Automatic Editing115
  - Automatic Edit Modes115
  - Editing Precautions115
- Setting Switches and Menus116
- Selecting the Edit Mode117
- Setting Edit Points117
- Split Editing118
- Editing Non-Audio Data120
- Confirming Edit Points120
- Cuing up and Prerolling121
- Previewing121
- Modifying Edit Points122
- Deleting Edit Points122
- Performing Automatic Editing124
Advanced Automatic Editing126
- DMC Editing126
- Animation Editing127
- Preread Editing127
Manual Editing129
Appendix130
Maintenance130
- Head Cleaning130
- Moisture Condensation130
Specifications131
Error Messages and Warning Messages134
- Error Messages134
- Warning Messages135
- Error Log Menu137
  - Clearing Warning Messages138
  - Adjusting the Clock138
Glossary139
- Cue Point139
Menu List141
- Items Relating to VTR Operations (Nos. 001 to141
- Items Relating to Operation Panels (Nos. 101 to145
- Items Relating to Remote Interface (Nos. 201 to148
- Items Relating to Editing (Nos. 301 to149
- Items Relating to Prerolling (Nos. 401 to152
- Items Relating to Recording Protection (Nos. 501 to153
- Items Relating to the Time Code (Nos. 601 to154
- Items Relating to the Video Control (Nos. 706 to158
- Items Relating to the Audio Control (Nos. 807 to162
- Items Relating to Digital Processing (Nos. 902 to172
- Items Relating to the Pulldown Control (Nos. A01 to176
- Other Items (Nos. T01 to178
Index183
