2-5. REAR PANEL BLOCK
Six ‘black’
screws +BV3(3-CR)
Rear panel block
5
Two screws+P 3X3
(tightening torque = 6 to 7 kgf•cm)
2
(tightening torque = 4 to 5 kgf•cm)
3
2-3
2-6. MB-139 BOARD
Six screws +BV3(3-CR)
(tightening torque = 6 to
7 kgf•cm)
MB-139 board
(CN2470)
1 Harness(PM-161)
(CN301)
6
Flex bl e fla t
(CN2460)
5
Flexibl e fla t
4
(CN1204)
3 Harness (FLM-003)
(CN1203)
Flexibl e fla t
8
7
PS Insulator top
1
BDP-BX58/S480/S483/S580
2 Flexible flat cable
(FIM-029)
cable (LDG-001)
cable (SPD-001)
cable (OPT-001)
(CN1301)
Harness
4
CN1503
