Sony BDP-S580 - Board Printed Wiring Board

5-2
BDP-BX58/S480/S483/S580
There are a few cases that the part isn’t mounted in this model is printed on this diagram.
: Uses unleaded solder.
5-2. FL-203 (REAR) BOARD PRINTED WIRING BOARD
- Ref. No.: FL-203 board; 20,000 series -
• See page 2-5 for circuit boards location.
FL-203 BOARD (S DE A)
CN331 A-1
FL-203 BOARD (SIDE A)
A
1
2
11
1-882-035-
