Sony DCR-PC109 - Flexible Boards Location

2-7E
DCR-PC109/PC109E
2. DISASSEMBLY
2. DISASSEMBLY
2-4. FLEXIBLE BOARDS LOCATION
The flexible boards contained in the lens block is not shown.
CONTROL KEY BLOCK
(SB6300)
CONTROL SWITCH BLOC
K
(SS6800)
CONTROL SWITCH BLOCK
(ZM6800)
FP-845
FP-926
FP-842
FP-844
FP-848
FP-841
FP-843
FP-839
FP-847
FP-846
