5-23
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DSLR-A300_L2
A-1437-492-A GY-008 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
C6201 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C6202 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C6203 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C6204 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
< SENSOR >
SE6201 1-480-049-31 SENSOR, ANGULAR VELOCITY (PITCH)
SE6202 1-480-049-31 SENSOR, ANGULAR VELOCITY (YAW)
A-1382-347-A CCD ASSY 627 (Note)
(Not supplied) IS-026 BOARD, COMPLETE
**********************
(IS-026 complete board and all mounted parts (including IC4303 (CCD
imager)) are not supplied, but they are included in CCD assy 627.)
A-1466-493-A LF-057 FLEXIBLE BOARD, COMPLETE
******************************
< CAPACITOR >
C9453 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C9455 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C9456 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C9457 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C9458 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C9459 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C9460 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
* C9461 1-100-910-91 CERAMIC CHIP 10uF 20% 10V
C9462 1-114-750-91 CERAMIC CHIP 2.2uF 20% 16V
C9465 1-100-660-91 CERAMIC CHIP 1uF 10% 10V
C9466 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C9467 1-114-098-91 CERAMIC CHIP 2.2uF 20% 25V
< CONNECTOR >
* CN9451 1-821-202-71 CONNECTOR, FPC (ZIF) 45P
< RESISTOR >
R9456 1-216-864-11 SHORT CHIP 0
R9457 1-216-857-11 METAL CHIP 1M 5% 1/10W
R9458 1-216-864-11 SHORT CHIP 0
A-1442-603-A MA-450 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
* CN5902 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
* CN5903 1-816-647-51 FFC/FPC CONNECTOR (LIF) 18P
* CN5904 1-816-645-51 FFC/FPC CONNECTOR (LIF) 14P
GY-008 IS-026 LF-057 MA-450
MM-076 RM-096 ST-196
A-1437-495-A MM-076 BOARD, COMPLETE
************************
< CAPACITOR >
C5202 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5203 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5205 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN5201 1-820-857-71 CONNECTOR, FPC (ZIF) 51P
CN5202 1-818-139-11 PIN, CONNECTOR (CF CARD)
(COMPACTFLASH/MICRODRIVE)
* CN5203 1-821-457-11 CONNECTOR, CARD (COMPACTFLASH)
(CF CARD EJECT LEVER)
< RESISTOR >
R5244 1-218-977-11 RES-CHIP 100K 5% 1/16W
R5246 1-218-977-11 RES-CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB5201 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5202 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5203 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5204 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5205 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5206 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5207 1-234-372-11 RES, NETWORK 100 (1005X4)
RB5208 1-234-372-11 RES, NETWORK 100 (1005X4)
A-1442-602-A RM-096 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
C8601 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C8602 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< LINE FILTER >
LF8601 1-457-088-21 COIL,COMMOM MORD CHOKE
A-1437-493-A ST-196 BOARD, COMPLETE
**********************
3-277-350-01 TAPE (62300), CAPACITOR FIXED
< CAPACITOR >
0* C901 1-114-603-11 ELECT 250uF 330V
C6501 1-119-667-11 CERAMIC CHIP 22uF 10V
C6502 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C6504 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C6506 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6507 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
* CN6501 1-816-644-51 FFC/FPC CONNECTOR (LIF) 12P
* CN6503 1-821-666-11 PIN, CONNECTOR
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
• Refer to page 5-1 for mark 0.
Ver. 1.2 2008.06
The changed portions from
Ver. 1.1 are shown in blue.
Note: イメージャの交換時は4-2ページのイメージャ交
換時の注意を必ずお読みください。

Sony DSLR-A300 Specifications

General

Megapixel	10.2 MP
Camera type	SLR Camera Body
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	- \
Supported aspect ratios	3:2, 16:9
Maximum image resolution	3872 x 2592 pixels
Still image resolution(s)	1920 x 1280, 2048 x 1536, 2592 x 1944, 3872 x 2592
Digital zoom	3 x
Optical zoom	2 x
Focal length range	- mm
Interface	USB 2.0
Power source	7.2V
Video capability	No
Power source type	Battery
Aperture range (F-F)	-
Camera shutter speed	30 - 1/4000 s
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Light exposure control	Program AE
Field of view	95 %
Display diagonal	2.7 \
Display resolution (numeric)	230400 pixels
Magnification	0.74 x
Viewfinder type	Optical
Scene modes	Close-up (macro), Night, Night landscape, Night portrait, Portrait, Sports, Sunset, Twilight, Landscape (scenery)
Image editing	Resizing, Rotating
Photo effects	Black&White, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Shade, Tungsten
Image processor	BIONZ
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, GRE, HUN, ITA, LAV, NOR, POL, POR, RUS, SWE, TUR
Product color	Black
Battery type	NP-FM500H
Battery capacity	1600 mAh
Battery life (CIPA standard)	730 shots
Number of batteries supported	1
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash guide number	12 m
Flash recharging time	4 s
Internal memory	- MB
Compatible memory cards	CF, MicroDrive, MS Duo, MS PRO Duo
Camera shutter type	Electronic
Maximum video resolution	- pixels
Cables included	AV, USB

Weight and Dimensions

Depth	74.7 mm
Width	130.8 mm
Height	98.5 mm
Weight	582 g
