4-36
DSLR-A300_L2
Refer to page 4-2 for mark 0.
ST-196
FLASH UNIT (FL62700) is replaced as block,
so that there PRINTED WIRING BOARD
and SCHEMATIC DIAGRAM are omitted.
A
D
7
CC
6
D
B
E
A
5
B
34
F
2
F
E
1 8
C6501
22u
F
Q6501
RJP4002ASA-00-Q0
FLASH DRIVE
1
8
5
2
3
4
6
7
LD6502
MC-
R6507
1M
LD6501
C901
250u
330V
CHARGING
CAPACITOR
MC+
R6506
68
C6502
22u
D6502
RR264M-400
R6501
3M
R6502
27k
1/10W
±0.5%
CN6503 2P
1 XE_K
2 IGBT_C
34
CN6504 2P
1 GND
2 GND
34
C6503
XX
R6510
100k
CL6501
CL6502
CL6503
CL6504
CL6506
R6513
1k
R6514
1k
C6504
22p
IC6501
BD4216NUV-E2
CHARGE CONTROL,
FLASH CONTROL
1
PGND
2
IGBT_OUT
3
IGBT_IN
4
X_FULL
5
ADJ
6
CHARGE
7
VCC
8
VC
9
NC
10
PVC
11
HGND
D6501
FV02R80TP
C6506
1u
C6507
0.1u
R6515
XX
R6516
100k
LD6503
(For Discharge)
(For Discharge)
+
LD6504
-
T6501
2
1
5
3
4
CN6501 12P
1UNREG
2UNREG
3UNREG
4PGND
5PGND
6PGND
7INT_FLASH_TRIGGER
8EVER_3.3V
9FULL_DET
10INT_FLASH_CHARGE
11INT_FLASH_FULL
12REG_GND
05
XX MARK:NO MOUNT
FLASH DRIVE
ST-196 BOARD
FLASH
UNIT
(FL62700)
EVER_3.3V
FLEXIBLE
LN6231-LN6242
of Level 2
Page 4-29
