HCD-DZ370/DZ560/DZ570/DZ660/DZ777
26
3-6. MAIN BOARD
3-5. DVD MECHANISM DECK
CN1201 (6P)
wire (flat type)(24 core)
(CN1101)
wire (flat type)(5 core)
(CN1202)
screw
(+BV3 (3-CR))
two screws
(+BV3 (3-CR))
DVD mechanism deck
screw
(+BV3 (3-CR))
screw
(+BV3 (3-CR))
screw
(+BV3 (3-CR))
cover (CDM-DSR)
CN114 (8P)
wire (flat type)(5 core)
(CN702)
two screws
(+BV3 (3-CR))
two screws
(+BV3 (3-CR))
RB two screws
(+BV3 (3-CR))
RT six screws
(+BV3 (3-CR))
RE MAIN board
heat sink section
two radiation sheet
SPEAKER board
wire (flat type) (19 core) (CN602)
(DZ560/DZ660)
wire (flat type) (17 core) (CN603)
(DZ370/DZ570/DZ777)
wire (flat type) (19 core) (CN4301) (DZ560/DZ660)
wire (flat type) (17 core) (CN4302) (DZ370/DZ570/DZ777)
screw
(+BVTP 3 × 12)
