HCD-DZ370/DZ560/DZ570/DZ660/DZ777
27
3-8. TRAY
3-7. IO-SCART BOARD (DZ560/DZ660), IO-COMPONENT BOARD (DZ370/DZ570/DZ777)
two screws
(+BV3 (3-CR))
IO-SCART board (DZ560/DZ660)
IO-COMPONENT board (DZ370/DZ570/DZ777)
two claws
tray
Move the chuck cam
in the direction of the arrow.
bottom side
