HCD-DZ370/DZ560/DZ570/DZ660/DZ777
51 2-889-990-01 KNOB (VOL)
52 3-273-726-01 ORNAMENT (DSR) (DZ370/DZ560/DZ570)
52 3-273-726-11 ORNAMENT (DSR) (DZ660/DZ777)
53 3-273-728-01 BUTTON (PLAY-SP) (DZ370/DZ560/DZ570/DZ660)
53 3-273-729-01 BUTTON (PLAY) (DZ777)
54 3-943-995-01 EMBLEM (NO. 5), SONY
55 3-273-724-51 WINDOW, INDICATION (DSR-1) (DZ570)
55 3-273-724-91 WINDOW, INDICATION (DSR-1) (DZ560)
55 3-273-725-01 WINDOW, INDICATION (DSR-2) (DZ777)
55 3-273-725-71 WINDOW, INDICATION (DSR-2) (DZ660)
55 3-273-725-81 WINDOW, INDICATION (DSR-2) (DZ370)
56 3-280-669-01 SHEET (DSR WINDOW), ADHESIVE
57 3-273-722-01 PANEL, FRONT (DSR-1) (DZ560/DZ660)
57 3-273-722-21 PANEL, FRONT (DSR-1) (DZ370/DZ570/DZ777)
58 3-273-730-01 BUTTON (POWER-DSR)
59 3-273-732-01 FILTER, COLOR
60 3-273-731-01 HOLDER (FL)
61 A-1382-431-A FL BOARD, COMPLETE
62 3-087-053-01 +BVTP 2.6 (3CR)
63 1-828-307-11 WIRE (FLAT TYPE) (9 CORE)
64 1-828-363-11 WIRE (FLAT TYPE) (19 CORE)
65 A-1382-433-A JACK BOARD, COMPLETE
(EXCEPT E12,E32,MX,PX)
65 A-1382-542-A JACK BOARD, COMPLETE (E12,E32,MX,PX)
ND100 1-519-988-11 INDICATOR TUBE, FLUORESCENT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7-2. FRONT PANEL SECTION
Note: If the wire (fl at type) was replaced, fold it some as
the wire (fl at type) before replacement.
