HCD-DZ370/DZ560/DZ570/DZ660/DZ777
28
3-10. MS-203 BOARD
3-9. BELT
two claws
belt
chuck cam
three claws
MS-203 board
DC motor
screw
(M 1.7 × 2.5)
