HCD-GTZ2/GTZ2i/GTZ3/GTZ3i
8
2-9. HUB BOARD, DMB19 BOARD
2-10. CD MECHANISM BLOCK (CDM88B-DVBU101)
1 two screws
(BVTP3 u8)
qa connector
(DMB19 board: CN1105/
HUB board: CN1500)
qs two screws
(BVTP3 u8)
4 CD block
qf HUB
board
1 two screws
(BVTP3 u8)
5 chassis block
2
3 two screws
(BVTP3 u8)
qg four screws (BVTP3 u8)
7 flat (wire type) (9 core)
(CN1106)
qh DMB19 board
qd bracket
(ground hub)
0 connector (CN201)
6 flat (wire type)
(24 core) (CN101)
9 connector
(DMB19 board: CN601)
8 flat (wire type) (7 core)
(DMB19 board: CN4602)
qa screw
(BVTP3 u 8)
5 two screws (BVTP3 u8)
6 bracket (support)
8 cover dust (CDM88-B)
7 two saranet cushions
9 cover dust (CDM88-A)
1 flat (wire type) (13 core)
(MOTOR board)
0 three sheets (CDM)
qd CD mechanism block
(CDM88B-DVBU101)
qa two screws
(BVTP3 u8)
qs cover (CDM88 D-top)
2 screw
(BVTP3 u8)
3 bracket
(MTK)
4 ferrite core
7 saranet cushion
7 saranet cushion
