3-8. COVER (CDM-DCR)
connector
(CN1201)
cover (CDM-DCR)
wire (flat type) (24 core)
(CN1101)
ditch
Remove wire (flat type) (24 core)
from 2 ditches.
four screws
(BV3)
Remove lead wire
from 3 ditches.
lead wire
wire (flat type) (21 core)
(CN651)
three screws
(BVTP3
×
10)
DVD mechanism deck
(CDM81C-DVBU101)
3-9. DVD MECHANISM DECK (CDM81C-DVBU101)
