HCD-HDX275/HDX277WC/HDX279W/HDX475/HDX576WF/HDX675
SECTION 8
ELECTRICAL PARTS LIST
ENCODER BOARD (Included in RELAY board)
***************
*************************************************************
A-1436-203-A FL BOARD, COMPLETE
*******************
3-273-731-01 HOLDER (FL)
< CAPACITOR >
C101 1-124-584-00 ELECT 100uF 20% 6.3V
C102 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C103 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C105 1-119-772-91 ELECT 47uF 20% 35V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-126-157-11 ELECT 10uF 20% 16V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-126-157-11 ELECT 10uF 20% 16V
C117 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C194 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C195 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN100 1-779-546-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D100 6-501-579-01 DIODE MC2837
D101 6-501-579-01 DIODE MC2837
D102 6-501-729-01 DIODE MAZ8051GLLS0
D103 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC100 6-701-729-01 IC PT6315
IC101 6-600-349-21 IC NJL23H400A
< COIL >
L100 1-410-671-31 INDUCTOR 47uH
L101 1-410-671-31 INDUCTOR 47uH
L102 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND100 1-519-988-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q100 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R100 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R101 1-216-839-11 METAL CHIP 33K 5% 1/10W
R102 1-216-805-11 METAL CHIP 47 5% 1/10W
R103 1-216-805-11 METAL CHIP 47 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-844-11 METAL CHIP 82K 5% 1/10W
R108 1-216-805-11 METAL CHIP 47 5% 1/10W
< TRANSFORMER >
T100 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
A-1436-211-A I/O BOARD, COMPLETE
(HDX275/HDX475/HDX675)
A-1436-346-A I/O BOARD, COMPLETE (HDX576WF)
A-1539-127-A I/O BOARD, COMPLETE (HDX277WC/HDX279W)
*******************
< CAPACITOR >
C414 1-126-933-11 ELECT 100uF 20% 16V
C415 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C420 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C424 1-126-933-11 ELECT 100uF 20% 16V
C454 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C456 1-126-933-11 ELECT 100uF 20% 16V
C457 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C458 1-126-933-11 ELECT 100uF 20% 16V
C460 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C462 1-126-916-11 ELECT 1000uF 20% 6.3V
C468 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ENCODER
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
AUS : Australian model
E3 : 240V AC area in E model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
