HCD-HDX275/HDX277WC/HDX279W/HDX475/HDX576WF/HDX675
17
3-10. TRAY (MAIN) ASSY
tray (main) assy
Remove the tray (main) assy
in the direction of the arrow.
bracket (top)
two screws
(BTTP M2.6)
two screws
(BTTP M2.6)
screw
(BTTP M2.6)
bracket
screw
(BTTP M2.6)
MOTOR board
Remove two solders.
motor (81) assy (LD/ST motor)
(M761)
Remove two solders.
motor (81) assy (BU U/D motor)
(M762 )
3-11. MOTOR BOARD
