HCD-HDX275/HDX277WC/HDX279W/HDX475/HDX576WF/HDX675
9
SECTION 2
GENERAL
This section is extracted
from instruction manual.
Index to Parts and Control
For more information, refer to the pages indicated in parentheses.
" / (on/standby)
# " (open/close)
$ Front panel display
% Play operation buttons
& (remote sensor)
' FUNCTION
( VOLUME control
) PHONES jack
* AUDIO IN/A.CAL MIC jack
+ DISC 1-5 buttons/indicators
, Disc tray
Front panel
HCD-HDX275/HDX475/HDX675
" SPEAKER jacks
# EZW-T100 slot
$ F
MCOAXIAL75Ω jack
% AM terminal
& TV/VIDEO (AUDIO IN R/L) jacks
' VIDEO OUT jack
( COMPONENT VIDEO OUT jacks
) DMPORT (DIGITAL MEDIA PORT) jack
* HDMI OUT jack
+ TV/VIDEO (DIGITAL IN COAXIAL/
OPTICAL) jacks
* CAUTION
Please do not remove the screws before
installing the EZW-T100.
Rear panel
CENTER SUBWOOFER
DIGITAL IN
P
B
/C
B
P
R
/C
R
AUDIO IN LRY
COAXIAL OPTICAL
FRONT R FRONT L SUR R SUR L
SPEAKER
COMPONENT VIDEO OUT
TV/VIDEO
TV/VIDEO
SPEAKER
EZW-T100
COAXIAL 75
AM
FM
DMPORT
ANTENNA
HDMI OUT
VIDEO
OUT
DC5V
0.7A MAX
Screws*
