HCD-RV660D/RV990D
2-5. TAPE MECHANISM DECK
2-6. PANEL BOARD, LED BOARD, REMOTE BOARD
2
two
screws
(+BVTP 2.6
×
8)
4
two
screws
(+BVTP 2.6
×
8
)
3
three
screws
(+BVTP 2.6
×
8)
5
tape mechanism deck
1
connector
1
volume knob
8
PANEL board
0
LED board
qs
REMOTE board
7
two claws
qa
CN102
2
three
screws
(+BVTP 2.6
×
8)
3
two
screws
(+BVTP 2.6
×
8)
4
two
screws
(+BVTP 2.6
×
8
)
9
two
screws
(+BVTP 2.6
×
8)
6
two
screws
(+BVTP 2.6
×
8)
5
three
screws
(+BVTP 2.6
×
8)
