14
HCD-RV660D/RV990D
2-13. PICK-UP UNIT
2-14. SW BOARD, DRIVER BOARD
9
two insulators
0
insulator
5
RF board
2
two screws
(+BTP M2.6)
qa
pick-up unit
holder (DBU) assy
3
CN003
4
CN001
1
floating
screw
(+PTPWH M2.6
)
6
floating
screw
(+PTPWH M2.6)
7
floating
screw
(+PTPWH M2.6)
8
floating
screw
(+PTPWH M2.6)
6
DRIVER boar
d
2
SW board
3
CN704
4
CN703
7
CN702 (flat type)
5
two
screws
(+BTTP (M2.6))
1
screw
(+BTTP (M2.6))
