HCD-RV660D/RV990D
1-1. CD MECHANISM BLOCK
1. SERVICE POSITIONS
1-2. TC MECHANISM BLOCK
CD mechanism block
extension cable
MAIN board (CN101) – DMB03 board (CN101)
(Part No. J-2501-241-A)
extension cable
MAIN board (CN301) – DMB03 board (CN107)
HCD-RV660D: 13 core (Part No. J-2501-102-A)
HCD-RV990D: 25 core (Part No. J-2501-199-A)
TC mechanism bloc
k
Ver 1.2
