16
HCD-RV660D/RV990D
2-17. MOTOR (LD) BOARD
4
Remove the two solderings of motor.
3
MOTOR (LD) board
1
belt (loading)
5
loading motor assy (M751)
2
two
screws
(+BTTP (M2.6))
