HT-S20R
19
Sony CONFIDENTIAL
For Authorized Servicer
2-13. GRILLE ASSY_L (LEFT SIDE) (SS-S20R)
1 two screws
(BTP3 u 8)
1 three screws
(BTP3 u 8)
1 two screws
(BTP3 u 8)
1 three screws
(BTP3 u 8)
speaker block
(left side)
2 claw
2 claw
2 claw
2 claw
2 claw
2 claw
3
4 grille assy_L
(left side)
2-14. GRILLE ASSY_C (CENTER) (SS-S20R)
1 four screws
(BTP3 u 8)
1 four screws
(BTP3 u 8)
1 screw
(BTP3 u 8)
1 screw
(BTP3 u 8)
speaker block
(center)
3
4 grille assy_C
(center)
2 claw
2 claw
2 claw
2 claw
SYSSET
2021/02/1022:25:21(GMT+09:00)

Sony HT-S20R Specifications

General

Equalizer	Yes
Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	400 W
Audio output channels	5.1 channels
Surround modes quantity	4
Wi-Fi	-
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
Soundbar speaker RMS power	- W
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wired
Product color	Black
Wall mountable	No
Cables included	AC
Package type	Box
Package depth	553 mm
Package width	843 mm
Package height	248 mm
Package weight	13000 g
AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz

Weight and Dimensions

Depth	86 mm
Width	760 mm
Height	52 mm
Soundbar weight	2000 g
Subwoofer depth	342 mm
Subwoofer width	192 mm
Subwoofer height	387 mm
Subwoofer weight	6900 g
