Sony HT-S20R User Manual

HT-S20R
22
Sony CONFIDENTIAL
For Authorized Servicer
SECTION 3
TROUBLESHOOTING
“HELLO” is displayed in the front panel
display when the AC power cord is
plugged into the AC outlet.
The cable of 9 pin connecting the
POWER board and the MAIN board is
inserted properly.
NG
The cable of 15 pin connecting the
MAIN board and the DISPLAY board is
inserted properly.
NG
Insert the cable into the correct position.
NG
Insert the cable into the correct position.
NG
Replace the POWER board.
“HELLO” is displayed.
NG
OK
It can turn the power on by pressing the
[1] button on the remote commandar.
OK
“PLEASE WAIT” is displayed, and
complete.
OK
Replace the DISPLAY board.
OK
OK
The voltage of the following is +21.5 V.
POWER board: CN901 pin 1 to 4 or
MAIN board: CN100 pin 1 to 4
1. Starting up (SA-WS20R)
2. TOUCH KEY board does not work (SA-WS20R)
The cable of 7 pin connecting the
DISPLAY board and the TOUCH KEY
board is inserted properly.
NG
Check the disconnection of cable, and
repair it.
Insert the cable into the correct position.
NG
OK
Replace the TOUCH KEY board.
SYSSET
2021/02/1022:25:21(GMT+09:00)

Sony HT-S20R Specifications

General

Equalizer	Yes
Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	400 W
Audio output channels	5.1 channels
Surround modes quantity	4
Wi-Fi	-
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
Soundbar speaker RMS power	- W
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wired
Product color	Black
Wall mountable	No
Cables included	AC
Package type	Box
Package depth	553 mm
Package width	843 mm
Package height	248 mm
Package weight	13000 g
AC input voltage	220 - 240 V
AC input frequency	50 / 60 Hz

Weight and Dimensions

Depth	86 mm
Width	760 mm
Height	52 mm
Soundbar weight	2000 g
Subwoofer depth	342 mm
Subwoofer width	192 mm
Subwoofer height	387 mm
Subwoofer weight	6900 g
