Ref.No. Name Color Description Normal
state
D006 DPR-POWER Green Lights when all power voltages on the DPR-361
board are normal.
Lit
D201 MS-LED Red/Green Indicates state of access to the memory stick.
Lit red: Access to the memory stick in progress. Do
not remove the memory stick.
Lit green: The inserted memory stick can be re-
moved.
—
D601 EXT Green Lights when the external input Reference signal is
detected.
Off
D604 PLL NG Red Lights when there is a problem with the PLL on the
DPR-361 board.
Off
D800 CONF DONE Red Lights during download of FPGA (IC700) data on
the DPR-361 board or when a configuration error
occurs.
Off
D2050 CONF DONE Red Lights during download of FPGA (IC2000) data on
the DPR-361 board or when a configuration error
occurs.
Off
ENC-112 Board
ENC-112 board (Side B)
AB
1
2
D100
D101
D102
Ref.No. Name Color Description 通常状態
D100-D102 — Green Blinks when IC100 on the ENC-112 board func-
tions correctly.
Blinking
HXCU-TX70
1-13
