Connection of Equipment
75 Ω
75 Ω
Waveform
monitor
PIX
/CN-3662
SYNC/WF
/CN-3663
Signal
generator
Audio oscillator
Triax cable*
3
*1: Only when the optional CBK-HD02 is installed.
*2: Only when the optional CBK-CE01 is installed.
*3: Transmittable cable attenuation: 3.8 to 45.6 dB (100 MHz)
When Fujikura φ8.5 mm cable is used: 50 to 600 m
HD camera control unit
HXCU-TX70
REFERENCE
/CN-3662
HD camera adaptor
CA-TX70
HD color camera
HXC-D70
Solid-state memory camcorder
PMW-500*
1
/400*
2
/350*
2
/320*
2
or
CCA-5 cable
(max. 50 m)
Remote control p anel
RCP-1000 series
Initial Settings
Make the following settings before starting adjustments.
After each adjustment is completed, be sure to restore the previous settings.
• CCU CONFIGURATION menu
C06: INTERCOM → SYSTEM I/F → RTS
C06: INTERCOM → TERMINATION → ON
C07: FRONT INCOM → INCOM MIC → CARBON
C07: FRONT INCOM → MIC GAIN → 0dB
• Front panel
INTERCOM switch → PROD
Except for these settings, do not change the switch settings made when the unit was shipped. (Refer to “1-9-2. Functions
of Onboard Switches”)
HXCU-TX70
5-2
