Sony HXR-NX5E User Manual

HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-28
Ref. No. Part No. Description Ref. No. Part No. Description
Ref. No. Part No. Description Ref. No. Part No. Description
R4467 1-208-661-11 METAL CHIP 120 0.5% 1/16W
R4468 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R4602 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R4805 1-218-990-81 SHORT CHIP 0
R4809 1-218-971-11 METAL CHIP 33K 5% 1/16W
R4810 1-208-886-81 METAL CHIP 910 0.5% 1/16W
R4816 1-218-935-11 METAL CHIP 33 5% 1/16W
R4817 1-218-935-11 METAL CHIP 33 5% 1/16W
R4818 1-218-935-11 METAL CHIP 33 5% 1/16W
R4819 1-218-935-11 METAL CHIP 33 5% 1/16W
R4820 1-218-935-11 METAL CHIP 33 5% 1/16W
R4821 1-218-935-11 METAL CHIP 33 5% 1/16W
R4822 1-218-935-11 METAL CHIP 33 5% 1/16W
R4823 1-218-935-11 METAL CHIP 33 5% 1/16W
R4824 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R4826 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R4827 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5015 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5016 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5017 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5018 1-218-945-11 METAL CHIP 220 5% 1/16W
R5019 1-218-990-81 SHORT CHIP 0
R5201 1-218-990-81 SHORT CHIP 0
R5202 1-218-941-81 METAL CHIP 100 5% 1/16W
R5203 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R5204 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R5205 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R5208 1-218-990-81 SHORT CHIP 0
R5219 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5224 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R5229 1-242-967-81 METAL CHIP 1 5% 1/16W
R5230 1-216-864-11 SHORT CHIP 0
R5231 1-216-864-11 SHORT CHIP 0
R5232 1-216-864-11 SHORT CHIP 0
R5233 1-216-864-11 SHORT CHIP 0
R5234 1-216-864-11 SHORT CHIP 0
R5235 1-216-864-11 SHORT CHIP 0
R5236 1-218-990-81 SHORT CHIP 0
R5237 1-216-864-11 SHORT CHIP 0
R5238 1-216-864-11 SHORT CHIP 0
R5239 1-216-864-11 SHORT CHIP 0
R5240 1-216-864-11 SHORT CHIP 0
R5241 1-216-864-11 SHORT CHIP 0
R5242 1-216-864-11 SHORT CHIP 0
R5243 1-216-864-11 SHORT CHIP 0
R5244 1-216-864-11 SHORT CHIP 0
R5245 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R5246 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5247 1-218-990-81 SHORT CHIP 0
R5249 1-208-635-11 METAL CHIP 10 0.5% 1/16W
R5250 1-216-295-91 SHORT CHIP 0
R5251 1-216-295-91 SHORT CHIP 0
R5252 1-216-295-91 SHORT CHIP 0
R5253 1-216-295-91 SHORT CHIP 0
R5254 1-216-295-91 SHORT CHIP 0
R5255 1-216-295-91 SHORT CHIP 0
R5256 1-216-295-91 SHORT CHIP 0
R5257 1-216-295-91 SHORT CHIP 0
R5258 1-216-295-91 SHORT CHIP 0
R5260 1-216-295-91 SHORT CHIP 0
R5261 1-216-295-91 SHORT CHIP 0
R5262 1-216-295-91 SHORT CHIP 0
R5263 1-218-990-81 SHORT CHIP 0
R5264 1-218-990-81 SHORT CHIP 0
R5401 1-218-990-81 SHORT CHIP 0
R5403 1-218-990-81 SHORT CHIP 0
R5404 1-245-604-11 METAL CHIP 10M 5% 1/16W
R5405 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5406 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R5407 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R5408 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5410 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R5411 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5412 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5414 1-218-949-11 METAL CHIP 470 5% 1/16W
R5415 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5416 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5417 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5418 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5419 1-218-967-11 METAL CHIP 15K 5% 1/16W
R5420 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R5421 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R5422 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5423 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5429 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5432 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5433 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5434 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5435 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5436 1-218-990-81 SHORT CHIP 0
R5438 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5439 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R5440 1-218-990-81 SHORT CHIP 0
R5441 1-218-990-81 SHORT CHIP 0
R5443 1-218-983-11 METAL CHIP 330K 5% 1/16W
R5444 1-218-990-81 SHORT CHIP 0
R5445 1-218-990-81 SHORT CHIP 0
R5446 1-218-981-91 METAL CHIP 220K 5% 1/16W
R5448 1-218-990-81 SHORT CHIP 0
R5450 1-218-990-81 SHORT CHIP 0
R5605 1-218-941-81 METAL CHIP 100 5% 1/16W
R5607 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5608 1-218-990-81 SHORT CHIP 0
R5610 1-218-972-11 METAL CHIP 39K 5% 1/16W
R5611 1-218-972-11 METAL CHIP 39K 5% 1/16W
R5612 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5613 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5615 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5616 1-218-985-11 METAL CHIP 470K 5% 1/16W
R5619 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5621 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5622 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5623 1-218-953-11 METAL CHIP 1K 5% 1/16W
R5624 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5625 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5626 1-218-965-11 METAL CHIP 10K 5% 1/16W
R5627 1-218-973-11 METAL CHIP 47K 5% 1/16W
R5628 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5629 1-218-989-11 METAL CHIP 1M 5% 1/16W
R5630 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5631 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5632 1-216-864-11 SHORT CHIP 0
R5633 1-218-990-81 SHORT CHIP 0
R5636 1-218-977-11 METAL CHIP 100K 5% 1/16W
R5641 1-218-990-81 SHORT CHIP 0
R6019 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R6020 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6021 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R6032 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R6033 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R6036 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6037 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R6040 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6043 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R6047 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R6050 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6053 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6085 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R6086 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R6087 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6088 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R6089 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6090 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R6091 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R6101 1-218-990-81 SHORT CHIP 0
R6201 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R6202 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R6203 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6204 1-218-972-11 METAL CHIP 39K 5% 1/16W
R6211 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R6212 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R6217 1-218-972-11 METAL CHIP 39K 5% 1/16W
R6222 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6232 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6263 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6264 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R6268 1-218-990-81 SHORT CHIP 0
R6406 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R6408 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R6409 1-216-864-11 SHORT CHIP 0
R6411 1-216-864-11 SHORT CHIP 0
R6412 1-218-990-81 SHORT CHIP 0
R6413 1-218-990-81 SHORT CHIP 0
R6414 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6415 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6416 1-218-990-81 SHORT CHIP 0
R6417 1-218-990-81 SHORT CHIP 0
R6421 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6422 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6425 1-218-990-81 SHORT CHIP 0
R6426 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6427 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6428 1-218-968-11 METAL CHIP 18K 5% 1/16W
R6429 1-218-968-11 METAL CHIP 18K 5% 1/16W
R6430 1-218-971-11 METAL CHIP 33K 5% 1/16W
R6431 1-218-971-11 METAL CHIP 33K 5% 1/16W
R6432 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R6433 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R6435 1-208-947-11 METAL CHIP 330K 0.5% 1/16W
R6436 1-208-947-11 METAL CHIP 330K 0.5% 1/16W
R6437 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6438 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R6439 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R6440 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R6441 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R6443 1-218-929-11 METAL CHIP 10 5% 1/16W
R6508 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
R6515 1-216-864-11 SHORT CHIP 0
R6516 1-218-990-81 SHORT CHIP 0
R6610 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6611 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6612 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6615 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6616 1-218-975-11 METAL CHIP 68K 5% 1/16W
R6617 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6618 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6619 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6620 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6621 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6629 1-216-864-11 SHORT CHIP 0
R8006 1-208-918-11 METAL CHIP 20K 0.5% 1/16W
R8010 1-218-971-11 METAL CHIP 33K 5% 1/16W
R8013 1-218-929-11 METAL CHIP 10 5% 1/16W
R8014 1-218-941-81 METAL CHIP 100 5% 1/16W
R8015 1-218-941-81 METAL CHIP 100 5% 1/16W
R8016 1-218-941-81 METAL CHIP 100 5% 1/16W
R8017 1-218-935-11 METAL CHIP 33 5% 1/16W
R8018 1-219-570-11 METAL CHIP 10M 5% 1/10W
R8019 1-245-604-11 METAL CHIP 10M 5% 1/16W
R8025 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8026 1-218-970-11 METAL CHIP 27K 5% 1/16W
R8029 1-218-983-11 METAL CHIP 330K 5% 1/16W
R8030 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R8031 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R8032 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R8033 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
* R8034 1-208-869-11 METAL CHIP 180 0.5% 1/16W
R8035 1-218-969-11 METAL CHIP 22K 5% 1/16W
R8036 1-218-969-11 METAL CHIP 22K 5% 1/16W
R8037 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R8038 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R8039 1-218-941-81 METAL CHIP 100 5% 1/16W
R8040 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
* R8041 1-208-869-11 METAL CHIP 180 0.5% 1/16W
R8042 1-218-941-81 METAL CHIP 100 5% 1/16W
R8043 1-218-941-81 METAL CHIP 100 5% 1/16W
R8044 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8046 1-218-941-81 METAL CHIP 100 5% 1/16W
R8054 1-218-953-11 METAL CHIP 1K 5% 1/16W
R8055 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R8056 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R8057 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R8058 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
VC-582

Sony HXR-NX5E Specifications

General

Sensor type	CMOS
Total megapixels	1.037 MP
Optical sensor size	1/3 \
Filter size	72 mm
Digital zoom	1.5 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.1 - 82 mm
Focal length (35mm film equivalent)	36.1 - 722 mm
Flash memory	- GB
Memory slots	1
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	MS PRO Duo, MS Pro-HG Duo, SDHC
Maximum memory card size	32 GB
Focus adjustment	Auto/Manual
Macro focusing range	0.01 - ∞/0.8 - ∞ m
Normal focusing range	0.8 - ∞ m
Light exposure modes	Auto, Manual
Camera shutter speed	1/25 s
Display diagonal	3.2 \
Display resolution (numeric)	921600 pixels
Viewfinder type	-
Viewfinder resolution	122688 pixels
Viewfinder screen size	0.45 \
Product color	Black
Camcorder type	Handheld camcorder
Minimum illumination	1.5 lx
Capture modes	LP
Video resolutions	720 x 576, 1280 x 720, 1440 x 1080 pixels
Video formats supported	H.264, MPEG2, MPEG4
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
USB connector type	Mini-USB B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery type	NP-F570, CR2025
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	6.4 h
Battery technology	Lithium
Video recording time	2.8 h
Minimum RAM	512 MB
Minimum processor	Intel Core 2 Duo 2.20GHz
Minimum storage drive space	100 MB
Compatible operating systems	Windows XP/Vista/7
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	342 mm
Width	173 mm
Height	187 mm
Weight	2200 g
