Sony HXR-NX5E User Manual

HXR-NX5C/NX5E/NX5J/NX5M/NX5N/NX5P/NX5U
2-19
Ref. No. Part No. Description Ref. No. Part No. Description
A-1752-127-A AS-063 BOARD, COMPLETE
**********************
< CAPACITOR >
C1501 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1503 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1506 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1508 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1509 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1510 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1511 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1512 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1513 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1514 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1515 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1516 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1517 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1518 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1519 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C1520 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1521 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1526 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1527 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1528 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN1501 1-817-920-11 CONNECTOR, FPC (ZIF) 80P
CN1502 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN1503 1-816-645-61 FFC/FPC CONNECTOR (LIF) 14P
< FERRITE BEAD >
* FB1501 1-481-300-11 INDUCTOR, FERRITE BEAD
* FB1502 1-481-300-11 INDUCTOR, FERRITE BEAD
FB1503 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1504 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1505 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1506 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
FB1507 1-400-354-11 INDUCTOR, FERRITE BEAD (1005)
< FILTER >
FL1501 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL1502 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC1501 6-713-638-01 IC BU19502KV-E2
IC1502 6-703-977-01 IC R1114Q331D-TR-FA
* IC1503 6-714-696-01 IC MAX8586ETA+T
< FILTER >
LF1501 1-457-374-21 COMMOM MODE CHOKE COIL
< RESISTOR >
R1501 1-218-940-11 METAL CHIP 82 5% 1/16W
R1502 1-218-940-11 METAL CHIP 82 5% 1/16W
R1503 1-218-940-11 METAL CHIP 82 5% 1/16W
R1504 1-218-940-11 METAL CHIP 82 5% 1/16W
R1505 1-218-940-11 METAL CHIP 82 5% 1/16W
R1506 1-218-933-11 METAL CHIP 22 5% 1/16W
R1507 1-218-940-11 METAL CHIP 82 5% 1/16W
R1508 1-218-933-11 METAL CHIP 22 5% 1/16W
R1509 1-218-940-11 METAL CHIP 82 5% 1/16W
R1510 1-218-940-11 METAL CHIP 82 5% 1/16W
R1511 1-218-933-11 METAL CHIP 22 5% 1/16W
R1512 1-218-935-11 METAL CHIP 33 5% 1/16W
R1513 1-218-935-11 METAL CHIP 33 5% 1/16W
R1514 1-218-935-11 METAL CHIP 33 5% 1/16W
R1515 1-218-935-11 METAL CHIP 33 5% 1/16W
R1516 1-218-935-11 METAL CHIP 33 5% 1/16W
R1517 1-218-935-11 METAL CHIP 33 5% 1/16W
R1518 1-218-935-11 METAL CHIP 33 5% 1/16W
R1519 1-218-935-11 METAL CHIP 33 5% 1/16W
R1520 1-218-935-11 METAL CHIP 33 5% 1/16W
R1521 1-218-935-11 METAL CHIP 33 5% 1/16W
R1522 1-218-935-11 METAL CHIP 33 5% 1/16W
R1523 1-218-935-11 METAL CHIP 33 5% 1/16W
R1524 1-218-935-11 METAL CHIP 33 5% 1/16W
R1525 1-218-935-11 METAL CHIP 33 5% 1/16W
R1526 1-218-935-11 METAL CHIP 33 5% 1/16W
R1527 1-218-935-11 METAL CHIP 33 5% 1/16W
R1528 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1532 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1533 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1534 1-208-890-11 METAL CHIP 1.3K 0.5% 1/16W
R1535 1-218-989-11 METAL CHIP 1M 5% 1/16W
R1536 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1545 1-208-721-11 METAL CHIP 39K 0.5% 1/16W
R1546 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1549 1-218-990-81 SHORT CHIP 0
R1551 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X1501 1-813-210-11 VIBRATOR, CRYSTAL (NX5032GA) (25MHz)
A-1752-112-A CK-218 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN1001 1-779-335-51 CONNECTOR, FFC/FPC 22P
* CN1002 1-779-331-51 CONNECTOR, FFC/FPC 14P
CN1003 1-779-330-51 CONNECTOR, FFC/FPC 12P
* CN1004 1-817-560-71 CONNECTOR, FPC (ZIP) 21P
< RESISTOR >
R1001 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1002 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1003 1-218-970-11 METAL CHIP 27K 5% 1/16W
R1004 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R1005 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R1006 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R1007 1-218-964-11 METAL CHIP 8.2K 5% 1/16W
R1008 1-218-960-11 METAL CHIP 3.9K 5% 1/16W
AS-063 CK-218
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some
differences from the original one.
• Items marked “*” are not stocked since they are seldom re-
quired for routine service. Some delay should be anticipated
when ordering these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may
be different from the parts specified in the diagrams or the
components used on the set.
• CAPACITORS:
uF: F
• COILS
uH: H
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: , for example:
uA...: A... , uPA... , PA... ,
uPB... , PB... , uPC... , PC... ,
uPD..., PD...
(JAPANESE)

 

 

 
 
 
 
 
 
 

The components identified by mark 
or dotted line with mark  are critical for
safety.
Replace only with part number speci-
fied.
Les composants identifiés par une mar-
que  sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.



When indicating parts by reference num-
ber, please include the board name.



Caution




Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
2-1. ELECTRICAL PARTS LIST
The changed portions from
Ver. 1.0 are shown in blue.
Ver. 1.1 2010.01
ノート:





Note: Replace the battery holder (BH2001) together
when replacing the lithium storage battery
(BT2001) on the GC-012 board. (The battery
holder removed once cannot be used again.)
When mounting these parts, mount new battery
holder first and attach new lithium storage
battery next.

Sony HXR-NX5E Specifications

General

Sensor type	CMOS
Total megapixels	1.037 MP
Optical sensor size	1/3 \
Filter size	72 mm
Digital zoom	1.5 x
Optical zoom	20 x
Image stabilizer	Yes
Focal length range	4.1 - 82 mm
Focal length (35mm film equivalent)	36.1 - 722 mm
Flash memory	- GB
Memory slots	1
Camcorder media type	Memory card
Disc types supported	No
Compatible memory cards	MS PRO Duo, MS Pro-HG Duo, SDHC
Maximum memory card size	32 GB
Focus adjustment	Auto/Manual
Macro focusing range	0.01 - ∞/0.8 - ∞ m
Normal focusing range	0.8 - ∞ m
Light exposure modes	Auto, Manual
Camera shutter speed	1/25 s
Display diagonal	3.2 \
Display resolution (numeric)	921600 pixels
Viewfinder type	-
Viewfinder resolution	122688 pixels
Viewfinder screen size	0.45 \
Product color	Black
Camcorder type	Handheld camcorder
Minimum illumination	1.5 lx
Capture modes	LP
Video resolutions	720 x 576, 1280 x 720, 1440 x 1080 pixels
Video formats supported	H.264, MPEG2, MPEG4
Maximum video resolution	1920 x 1080 pixels
Maximum image resolution	- pixels
Audio system	Dolby Digital 2.0
PCM digital audio	16-bit/48 kHz
USB connector type	Mini-USB B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery type	NP-F570, CR2025
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	6.4 h
Battery technology	Lithium
Video recording time	2.8 h
Minimum RAM	512 MB
Minimum processor	Intel Core 2 Duo 2.20GHz
Minimum storage drive space	100 MB
Compatible operating systems	Windows XP/Vista/7
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	342 mm
Width	173 mm
Height	187 mm
Weight	2200 g
