Sony HXR-NX5R User Manual

101
Using the Menu
AUDIO LEVEL
DISPLAY
ON, OFF Sets whether to display the audio level meters.
ZOOM DISPLAY
BAR, NUMBER Sets whether to display the zoom position as a
bar or number.
FOCUS DISPLAY
METER, FEET Sets the display of the focus distance in meters
or feet.
SHUTTER DISPLAY
SECOND, DEGREE Sets the display of the shutter speed in seconds
or degrees.
The shutter speed equal to the period that your
camcorder reads image data from the image
sensor is defined as 360 degrees. The degree is
calculated based on this definition and
displayed.
• When you press the DATA CODE button,
the shutter speed is displayed in seconds
regardless of this setting.
• If the shutter speed is more than 360 degrees,
it is displayed as an integral multiple of 360
degrees (360 × 2, etc.).
LCD BRIGHT
NORMAL, BRIGHT Adjusts the brightness of the LCD screen.
• Changes in the LCD brightness do not affect
the brightness of recorded images.
VF COLOR TEMP.
–2/–1/0/+1/+2 (0) Sets the color temperature of the viewfinder.
Low color temperature makes the viewfinder
appear reddish, and high color temperature
makes it appear bluish.
DISPLAY OUTPUT
LCD PANEL, ALL
OUTPUT
Sets the output to display information, such as
the time code.
You can select to display information on the
LCD screen only, or output the information to
the VIDEO OUT, SDI OUT, HDMI OUT
jacks and the LCD screen. Zebra, peaking and
the frame on the face are also output.
• During marker display, only the time code,
zebra, peaking, and face detection indicators
are output, even if [DISPLAY OUTPUT] is
set to [ALL OUTPUT].
• You cannot display markers when using
[FOCUS MAGNIFIER].
DISPLAY SET
Menu item Sub-items/Settings Description
Continued ,

Sony HXR-NX5R Specifications

General

Camcorder type	Handheld camcorder
Minimum illumination	1 lx
Supported aspect ratios	4:3, 16:9
Product color	Black
DC-in jack	Yes
PictBridge	No
Composite video out	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	0
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Battery voltage	7.2 V
Battery capacity	- mAh
Battery life (max)	7.2 h
Battery technology	-
Video resolutions	720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate	50 fps
Video formats supported	AVC, AVCHD, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Bitrate at maximum video resolution	50 Mbit/s
Sensor type	CMOS
Total megapixels	2.07 MP
Optical sensor size	1/2.8 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	MS PRO Duo, SD, SDHC, SDXC
Maximum memory card size	64 GB
Internal storage capacity	- GB
Audio system	Dolby Digital
PCM digital audio	16-bit/48 kHz
Audio formats supported	PCM
Filter size	72 mm
Digital zoom	40 x
Optical zoom	20 x
Focal length range	4.1 - 82 mm
Maximum aperture number	3.4
Minimum aperture number	1.6
Focal length (35mm film equivalent)	28.8 - 576 mm
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/3 - 1/10000 s
Viewfinder type	Electronic
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables included	AC, USB
Maximum image resolution	- pixels
Display diagonal	8.8 \

Weight and Dimensions

Depth	385 mm
Width	176 mm
Height	199.5 mm
Weight	2110 g
