78
b Note
It is recommended that [Secure Protocol] be set
to [ON]. If set to [OFF], the user name,
password, and movie file data may be disclosed
to other parties if communication with the FTP
server is intercepted or if connected to an
unintended FTP server.
Select an FTP server to use for FTP transfer
from the list of registered FTP servers.
1 Press the MENU button.
2 Select (NETWORK SET) t
[FTP TRANSFER] t [FTP
SERVER SELECT].
3 Select the desired server.
You can transfer files by FTP using the
connected network.
1 Check that the network settings
are configured (p. 68).
2 Press the THUMBNAIL button.
3 Select the media, where the files
you want to transfer are stored,
and the file format on the
thumbnail screen.
4 Press the MENU button.
5 Select (NETWORK SET) t
[FTP TRANSFER] t [EXECUTE]
t network connection method.
The network connection starts.
The thumbnail screen appears when
connection to the FTP server is
successful.
6 Select the thumbnail of the file
you want to transfer, and select
.
Up to 100 files can be selected.
Press the DISPLAY button to preview
the image.
7 Select whether to turn the
camcorder off (YES) or not (NO)
automatically when the FTP
transfer is completed.
File transfer starts.
To cancel the transfer, select [Cancel].
If [YES] was selected in step 7, the
camcorder turns off automatically
when the transfer is completed.
If [NO] was selected, select [OK].
Selecting an FTP server
Using FTP transfer
Using the FTP transfer function (Continued)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony HXR-NX5R and is the answer not in the manual?

Sony HXR-NX5R Specifications

General IconGeneral
Camcorder typeHandheld camcorder
Minimum illumination1 lx
Supported aspect ratios4:3, 16:9
Product colorBlack
DC-in jackYes
PictBridgeNo
Composite video out1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out0
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Battery voltage7.2 V
Battery capacity- mAh
Battery life (max)7.2 h
Battery technology-
Video resolutions720 x 576, 1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Maximum frame rate50 fps
Video formats supportedAVC, AVCHD, H.264, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Bitrate at maximum video resolution50 Mbit/s
Sensor typeCMOS
Total megapixels2.07 MP
Optical sensor size1/2.8 \
Memory slots2
Camcorder media typeMemory card
Compatible memory cardsMS PRO Duo, SD, SDHC, SDXC
Maximum memory card size64 GB
Internal storage capacity- GB
Audio systemDolby Digital
PCM digital audio16-bit/48 kHz
Audio formats supportedPCM
Filter size72 mm
Digital zoom40 x
Optical zoom20 x
Focal length range4.1 - 82 mm
Maximum aperture number3.4
Minimum aperture number1.6
Focal length (35mm film equivalent)28.8 - 576 mm
Focus adjustmentAuto/Manual
Closest focusing distance0.01 m
Camera shutter speed1/3 - 1/10000 s
Viewfinder typeElectronic
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cables includedAC, USB
Maximum image resolution- pixels
Display diagonal8.8 \
Weight and Dimensions IconWeight and Dimensions
Depth385 mm
Width176 mm
Height199.5 mm
Weight2110 g
