FC-72 BOARD EEPROM LOCATION
3/14/01
CN001
IC404
Hi
CONTROL
CN001CN002
CN701
CN702
CN703
CN101
CN183
EEPROM
IC406
FC-72 BD.
FRONT
CN803
TO CPC-12
JIG
TO
FLOPPY
DRIVE
POWER
INPUT
FROM
FU BOARD
FC-72 BD.
BACK
EEPROM
IC508
CN402 (MVC95 ONLY)
10
1
91
12
1
1
19
1
5
1
5
1
18
1
26
FRONT
BACK
11DSC 1309
X401
1-767-980-21
