The following options are available in each menu. For details on navigating through menus, see
page 75.
Overview of the menus
Menu
[Display]
Parameters
[Display]
Settings Default
setting
Auto Calibration
settings
[<AUTO CAL>]
Auto Calibration (Standard)
[STANDARD]
ENGINEER
Auto Calibration (Custom)
[CUSTOM]
FULL FLAT, ENGINEER,
FRONT REF, OFF
FULL FLAT
Level settings
[<LEVEL>]
Test tone
b)
[TEST TONE]
OFF, AUTO xxx
c)
OFF
Front left speaker level
b)
[FL LEVEL]
FL –10.0 dB to FL +10.0 dB
(0.5 dB interval)
FL 0 dB
Front right speaker level
b)
[FR LEVEL]
FR –10.0 dB to FR +10.0 dB
(0.5 dB interval)
FR 0 dB
Center speaker level
b)
[CNT LEVEL]
CNT –10.0 dB to CNT +10.0 dB
(0.5 dB interval)
CNT 0 dB
Surround left speaker level
b)
[SL LEVEL]
SL –10.0 dB to SL +10.0 dB
(0.5 dB interval)
SL 0 dB
Surround right speaker level
b)
[SR LEVEL]
SR –10.0 dB to SR +10.0 dB
(0.5 dB interval)
SR 0 dB
Surround back speaker level
b)
[SB LEVEL]
SB –10.0 dB to SB +10.0 dB
(0.5 dB interval)
SB 0 dB
Surround back left speaker
level
b)
[SBL LEVEL]
SBL –10.0 dB to SBL +10.0 dB
(0.5 dB interval)
SBL 0 dB
Surround back right speaker
level
b)
[SBR LEVEL]
SBR –10.0 dB to SBR +10.0 dB
(0.5 dB interval)
SBR 0 dB
Front left high speaker level
b)
[LH LEVEL]
LH –10.0 dB to LH +10.0 dB
(0.5 dB interval)
LH 0 dB
Front right high speaker level
b)
[RH LEVEL]
RH –10.0 dB to RH +10.0 dB
(0.5 dB interval)
RH 0 dB
Subwoofer level
b)
[SW LEVEL]
SW –10.0 dB to SW +10.0 dB
(0.5 dB interval)
SW 0 dB
Dynamic range compression
[D. RANGE]
COMP. MAX, COMP. STD,
COMP. AUTO, COMP. OFF
COMP. AUTO
Speaker settings
[<SPEAKER>]
Speaker pattern
[SP PATTERN]
5/2.1 to 2/0
(20 patterns)
3/4.1
Front speakers size
b)
[FRT SIZE]
LARGE, SMALL LARGE
Center speaker size
b)
[CNT SIZE]
LARGE, SMALL LARGE
