STR-DN1010
16
SECTION 5
DIAGRAMS
• Circuit Boards Location
TUNER (FM/AM)
DIGITAL board
STANDBY DCDC board
POWER KEY board
HEADPHONE board
DISPLAY board
THERMAL SENSOR board
MAIN board
DSP board
CONNECTION board
VIDEO board
SAIR board
DIGITAL VIDEO board
