80
STR-DN1010
SECTION 7
ELECTRICAL PARTS LIST
CONNECTION BOARD
*****************
< CAPACITOR >
C800 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C801 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C803 1-126-963-11 ELECT 4.7uF 20% 50V
C804 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C805 1-126-963-11 ELECT 4.7uF 20% 50V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C808 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C809 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C817 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C818 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C819 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C820 1-100-152-91 CERAMIC CHIP 100PF 5% 100V
C858 1-112-100-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN800 1-770-386-11 CONNECTOR, BOARD TO BOARD 20P
CN801 1-770-386-11 CONNECTOR, BOARD TO BOARD 20P
CN802 1-770-383-11 CONNECTOR, BOARD TO BOARD 14P
CN803 1-770-410-11 CONNECTOR, BOARD TO BOARD 18P
CN804 1-770-410-11 CONNECTOR, BOARD TO BOARD 18P
CN805 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< IC >
IC800 8-759-710-97 IC NJM4565M-D
< RESISTOR >
R801 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R802 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R803 1-216-841-11 METAL CHIP 47K 5% 1/10W
R804 1-216-841-11 METAL CHIP 47K 5% 1/10W
R805 1-216-841-11 METAL CHIP 47K 5% 1/10W
R806 1-216-841-11 METAL CHIP 47K 5% 1/10W
R807 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R808 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
************************************************************
A-1755-471-A DIGITAL BOARD, COMPLETE (US, CND)
A-1755-501-A DIGITAL BOARD, COMPLETE (UK, AUS, ECE)
***********************
3-087-053-01 +BVTP2.6 (3CR)
< CAPACITOR >
C2000 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2003 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2006 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2007 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2009 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2011 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2016 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2017 1-135-372-31 ELECT 470uF 20% 10V
C2018 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2021 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2023 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2030 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2034 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2035 1-126-947-11 ELECT 47uF 20% 35V
C2038 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
(US, CND)
C2039 1-164-733-11 CERAMIC CHIP 820PF 10% 50V
(US, CND)
C2040 1-112-089-11 ELECT 47uF 20% 25V
(US, CND)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONNECTION DIGITAL
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
ECE : Continental European, East
European and Russian models
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
