1-9
VPL-VW70
1-3-10. GA Board
4 Two screws
(+BVTP 3 x 12)
2 Duct sheet (C)
Fan connector
6 Cover (G)
0
Remove the GA board
in the direction of the arrow
A .
8 Claw
9 Dowel
1 Two
claws
5 Claw
3 Remove harnesses from the five claws.
Fuse connector
assembly
Lead with connector
(LVDS)
Front Side
of Unit
G Holder
7 Two screws
(+PSW 3 x 8)
CN106
CN101
CN107
CN104
CN103
CN105
GA board
G Holder
A
Fan connector
Fan connector
