VPL-VW70
1-3-18. Extension Boards and Extension Cables
C
J board x 3
XQA board
E
MOLEX
service connector assembly (5P) x 2
C
JST
service connector assembly (8P)
H
JST
service connector assembly A (6P)
M
JST
service connector assembly A (3P)
J
Service connector assembly A (9P)
L
MOLEX
service connector assembly (8P)
N
JST
service connector assembly B (6P)
I
Harness
assembly A (5P)
A
MOLEX
service connector assembly (13P)
K
Service connector assembly (14P)
F
MOLEX
service connector assembly (14P)
B
MOLEX
service connector assembly (15P)
D
MOLEX
service connector assembly (4P)
G
Panel
extension flat cable (80P) x 3
X kit assembly (Part No. A-1602-191-A)
To Next Page
