XAV-701BT/741
6
2-4. TENSION SPRING (KF)
0HWKRGRILQVWDOOLQJWHQVLRQVSULQJ.)
Hang in order of A, B by pay
attention spring of direction.
tension spring (KF)
A
B
±'9'PHFKDQLVPGHFNEORFNERWWRPVLGHYLHZ±
1 Remove the
tension spring (KF)
from a hole.
2 Remove the
tension spring (KF)
from a hook.
3
tension spring (KF)
6SDFHU3:%VHWWLQJ
guide line
hole
damper (S)
spacer (PWB, 614)
chassis (M, 614) complete assy
(CHA2)
xxxxxxxxxxx
3
three precision
screws
(
P1.7
u
2.2
)
3
precision
screw
(
P1.7
u
2.2
)
4
claw
5
Remove the chassis (T, 614) sub assy
in the direction of an arrow.
7
chassis (T, 614)
sub assy
(CHA1)
1 Bend the claw in the direction of an arrow.
6
label (S)
2
Remove three solders
of
SENSOR board wire
.
– DVD mechanism deck block bottom side view –
:iUe settinJ
SERVO
board
SERVO
board
[white]
[red]
[black]
OK
NG
Note 1:
Fit between chassis and SERVO
board. Be careful wire not protrude
from this part.
Note 2:
Do not overlap
on the SERVO
board.
2-5. CHASSIS (T, 614) SUB ASSY (CHA1)
To Next Page
