Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
XAV-701BT/741
78
< VIBRATOR >
X203 1-814-367-11 QUARTZ CRYSTAL UNITS (30 MHz)
X501 1-795-059-21 VIBRATOR, CERAMIC (6 MHz)
X502 1-813-202-11 VIBRATOR, CRYSTAL (32.768 kHz)
************************************************************
A-1871-803-A MOTOR BOARD, COMPLETE
**********************
4-410-504-01 SCREW (+PTT 2.6X6), GROUND POINT
< CAPACITOR >
C7001 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7002 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7003 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7004 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7005 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C7006 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7007 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C7008 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7009 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7010 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7011 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7012 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C7013 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN7001 1-770-359-11 PIN, CONNECTOR (PC BOARD) 2P
CN7002 1-842-500-11 CONNECTOR, FFC/FPC (ZIF) 20P
< DIODE >
D7001 6-503-205-01 DIODE RKZ6.8B2KGP1
D7002 6-503-207-01 DIODE RKZ9.1B2KGP1
D7003 6-503-208-01 DIODE RKZ10B2KGP1
D7004 6-503-210-01 DIODE RKZ13B2KGP1
< IC >
IC7001 8-759-701-01 IC NJM2904M
IC7002 6-711-151-01
IC BA6285AFP-YE2
< PHOTO INTERRUPTER >
PH7001 8-719-069-53 PHOTO INTERRUPTER CPI-210-T
< TRANSISTOR >
Q7001 6-552-430-01 TRANSISTOR DRC5114E0L
Q7002 6-552-430-01 TRANSISTOR DRC5114E0L
Q7003 6-551-431-01 TRANSISTOR 2SC6027T100-QR
Q7004 6-552-514-01 TRANSISTOR 2SCR533DTL
Q7005 6-553-011-01 TRANSISTOR 2SAR533DTL
Q7006 6-552-430-01 TRANSISTOR DRC5114E0L
Q7007 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q7008 6-552-430-01 TRANSISTOR DRC5114E0L
< RESISTOR >
R7001 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R7002 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R7004 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7005 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7006 1-218-236-91 METAL CHIP 1 10% 1/4W
R7007 1-218-236-91 METAL CHIP 1 10% 1/4W
R7008 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R7009 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R7010 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R7011 1-216-864-11 SHORT CHIP 0
R7012 1-216-864-11 SHORT CHIP 0
R7013 1-216-190-00 METAL CHIP 470 5% 1/8W
R7014 1-216-815-11 METAL CHIP 330 5% 1/10W
R7015 1-216-190-00 METAL CHIP 470 5% 1/8W
R7016 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7017 1-216-838-11 METAL CHIP 27K 5% 1/10W
R7018 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7019 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7020 1-216-821-11 METAL CHIP 1K 5% 1/10W
R7021 1-216-864-11 SHORT CHIP 0
R7022 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7023 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7024 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7025 1-216-839-11 METAL CHIP 33K 5% 1/10W
R7026 1-216-803-11 METAL CHIP 33 5% 1/10W
R7027 1-216-803-11 METAL CHIP 33 5% 1/10W
R7028 1-216-803-11 METAL CHIP 33 5% 1/10W
R7029 1-216-803-11 METAL CHIP 33 5% 1/10W
R7030 1-216-803-11 METAL CHIP 33 5% 1/10W
R7031 1-216-803-11 METAL CHIP 33 5% 1/10W
R7034 1-216-864-11 SHORT CHIP 0
R7035 1-216-864-11 SHORT CHIP 0
< SWITCH >
S7001 1-798-066-11 SWITCH, PUSH (MONITOR OPEN DETECT)
S7002 1-798-065-11 SWITCH, PUSH (MONITOR CLOSE DETECT)
< THERMISTOR >
TH7001 1-804-949-11 THERMISTOR, NTC (SMD)
************************************************************
SENSOR BOARD
*************
< SWITCH >
SW2 1-798-173-31 DETECTOR SWITCH (SELF)
SW3 1-798-173-31 DETECTOR SWITCH (DISC IN)
************************************************************
A-1848-243-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR/RESISTOR >
C1 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C2 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C9 1-135-856-91 TANTAL. CHIP 100uF 20% 10V
C10 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C11 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C12 1-135-856-91 TANTAL. CHIP 100uF 20% 10V
C13 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C14 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C15 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C16 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C17 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
MAIN MOTOR SENSOR SERVO
