XAV-701BT/741
XAV-701BT/741
5050
5-18. PRINTED WIRING BOARDS - PANEL Section -
• : Uses unleaded solder.
• See page 35 for Circuit Boards Location.
Note 3: CN7301 cannot exchange with single. When this part
is damaged, exchange the complete mounted board.
Note 1: When DISPLAY board is detective, exchange the complete mounted board, and exchanged
old complete DISPLAY board and is destroyed with the hammer, and throw out it.
Note 2: When KEY7 board is detective, exchange
the complete mounted board.
CN7302
R7311
R7312
R7313
R7314
CN7301
1-886-024-
11
(11)
1-886-024-
11
(11)
B
MAIN BOARD
CN901
D-SUB7 BOARD (SIDE A) D-SUB7 BOARD (SIDE B)
FPB1
(CHASSIS)
1 60
159
260
(CHASSIS)
DISPLAY
BOARD
KEY7
BOARD
TPN1
TOUCH
PANEL
LCD1
LIQUID
CRYSTAL
DISPLAY
PANEL
A
B
C
D
1 2 3 4 5 6 7 8 9 10 11 12 13
(Page 40)
To Next Page
