Sony XAV-701BT User Manual

XAV-701BT/741
25
3-18. DC FAN (25X25) (M801), MAIN BOARD
3-19. MOTOR ASSY
2 connector (CN803)
7 MAIN board
D401
6 thermal conductive
pad T8
thermal conductive
pad T8
MAIN board
CN803
1 fuse (blade type) (auto fuse)
(F801)
5 DC fan
(25 u 25)
(M801)
:LUHVHWWLQJ
7KHUPDOFRQGXFWLYHSDG7VHWWLQJ
NG
OK
3 screw
(PTT2.6 u 14)
4 sheet (GPS wire)
3 screw
(PTT2.6 u 14)
DC fan (25 u 25) (M801)
sheet (GPS wire)
D401
D401
D401
thermal conductive
pad T8
thermal conductive
pad T8
thermal conductive
pad T8
guide line
thermal conductive
pad T8
thermal conductive
pad T8
thermal conductive
pad T8
D401
D401
D401
guide line
1 screw
(PTT2.6 u 6)
7 screw
(PTT2.6 u 6)
8 bracket (front7)
9 motor assy
3 chassis (R)
1 screw
(PTT2.6 u 6)
4 screw
(PTT2.6 u 6)
4 screw
(PTT2.6 u 6)
2 screw
(Z S2.6 u 4)
2 screw
(Z S2.6 u 4)
5 screw
(Z S2.6 u 4)
5 screw
(Z S2.6 u 4)
6 chassis (L)
Note: When the complete MAIN board is replaced, the destination setting
is necessary. Refer to “NOTE THE MAIN BOARD OR SYSTEM
CONTROLLER (IC502) REPLACING” on page 5.
Ver. 1.2
