Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
XAV-701BT/741
80
< FERRITE BEAD/RESISTOR >
FB1 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB2 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB3 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB4 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB5 1-414-385-21 INDUCTOR, FERRITE BEAD
FB6 1-414-385-21 INDUCTOR, FERRITE BEAD
FB7 1-414-385-21 INDUCTOR, FERRITE BEAD
FB8 1-414-385-21 INDUCTOR, FERRITE BEAD
FB11 1-216-864-11 SHORT CHIP 0
FB12 1-208-859-81 METAL CHIP 68 0.5% 1/16W
FB13 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB14 1-469-083-21 INDUCTOR, FERRITE BEAD (1005)
FB15 1-414-385-21 INDUCTOR, FERRITE BEAD
FB16 1-414-385-21 INDUCTOR, FERRITE BEAD
FB17 1-414-385-21 INDUCTOR, FERRITE BEAD
FB18 1-400-693-21 INDUCTOR, FERRITE BEAD (1005)
FB19 1-400-693-21 INDUCTOR, FERRITE BEAD (1005)
FB20 1-414-385-21 INDUCTOR, FERRITE BEAD
FB21 1-414-229-11 INDUCTOR, FERRITE BEAD
FB22 1-414-385-21 INDUCTOR, FERRITE BEAD
FB23 1-414-385-21 INDUCTOR, FERRITE BEAD
FB24 1-500-284-21 INDUCTOR, FERRITE BEAD
FB25 1-414-385-21 INDUCTOR, FERRITE BEAD
FB26 1-500-284-21 INDUCTOR, FERRITE BEAD
FB27 1-500-284-21 INDUCTOR, FERRITE BEAD
FB28 1-414-385-21 INDUCTOR, FERRITE BEAD
FB29 1-414-385-21 INDUCTOR, FERRITE BEAD
FB31 1-500-284-21 INDUCTOR, FERRITE BEAD
FB32 1-414-385-21 INDUCTOR, FERRITE BEAD
FB33 1-414-385-21 INDUCTOR, FERRITE BEAD
FB35 1-216-864-11 SHORT CHIP 0
FB36 1-216-864-11 SHORT CHIP 0
FB37 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB38 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB39 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB40 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB41 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB42 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB43 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB44 1-414-385-21 INDUCTOR, FERRITE BEAD
FB45 1-414-385-21 INDUCTOR, FERRITE BEAD
FB46 1-414-385-21 INDUCTOR, FERRITE BEAD
FB47 1-414-385-21 INDUCTOR, FERRITE BEAD
FB48 1-414-229-11 INDUCTOR, FERRITE BEAD
FB49 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB50 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
FB51 1-414-229-11 INDUCTOR, FERRITE BEAD
FB52 1-457-421-21 INDUCTOR, FERRITE BEAD (1608)
< IC >
IC1 6-709-369-01 IC BH5510KV-E2
IC4 (Not supplied) IC ZR36988HQCG-AN
IC6 6-710-867-01 IC PCM1680DBQ
IC7 6-710-554-01 IC PCM1808PWR
IC10 6-714-642-01 IC EM638165 TSA-6G
IC11 (Not supplied) IC EN29LV320BB-70TIP
< FERRITE BEAD >
L1 1-469-407-22 INDUCT
OR, FERRITE BEAD
L10 1-469-407-22 INDUCTOR, FERRITE BEAD
L11 1-469-407-22 INDUCTOR, FERRITE BEAD
L22 1-481-420-21 INDUCTOR, FERRITE BEAD
L23 1-481-420-21 INDUCTOR, FERRITE BEAD
< TRANSISTOR >
Q4 6-551-120-01 TRANSISTOR 2SA2119K
Q6 6-551-120-01 TRANSISTOR 2SA2119K
< RESISTOR/FERRITE BEAD >
R3 1-242-967-11 METAL CHIP 1 5% 1/16W
R4 1-218-935-11 METAL CHIP 33 5% 1/16W
R5 1-218-935-11 METAL CHIP 33 5% 1/16W
R8 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R9 1-242-967-11 METAL CHIP 1 5% 1/16W
R11 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R12 1-218-968-11 METAL CHIP 18K 5% 1/16W
R13 1-218-968-11 METAL CHIP 18K 5% 1/16W
R14 1-218-967-11 METAL CHIP 15K 5% 1/16W
R15 1-218-966-11 METAL CHIP 12K 5% 1/16W
R16 1-218-966-11 METAL CHIP 12K 5% 1/16W
R18 1-218-945-11 METAL CHIP 220 5% 1/16W
R19 1-218-945-11 METAL CHIP 220 5% 1/16W
R21 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R22 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R23 1-218-937-11 METAL CHIP 47 5% 1/16W
R24 1-218-937-11 METAL CHIP 47 5% 1/16W
R25 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R26 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R27 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R28 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R29 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R30 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R31 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R32 1-218-990-81 SHORT CHIP 0
R33 1-218-977-11 METAL CHIP 100K 5% 1/16W
R34 1-218-943-11 METAL CHIP 150 5% 1/16W
R35 1-218-943-11 METAL CHIP 150 5% 1/16W
R36 1-218-977-11 METAL CHIP 100K 5% 1/16W
R37 1-218-990-81 SHORT CHIP 0
R38 1-218-990-81 SHORT CHIP 0
R39 1-218-941-81 METAL CHIP 100 5% 1/16W
R42 1-218-977-11 METAL CHIP 100K 5% 1/16W
R44 1-218-941-81 METAL CHIP 100 5% 1/16W
R49 1-218-977-11 METAL CHIP 100K 5% 1/16W
R50 1-208-702-11 METAL CHIP 6.2K 0.5% 1/16W
R51 1-218-977-11 METAL CHIP 100K 5% 1/16W
R54 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R55 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R56 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R57 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R58 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R60 1-469-581-21 INDUCTOR, FERRITE BEAD (1005)
R61 1-220-168-11 METAL CHIP 62 5% 1/16W
R62 1-218-989-11 METAL CHIP 1M 5% 1/16W
R63 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R65 1-218-977-11 METAL CHIP 100K 5% 1/16W
R66 1-218-977-11 METAL CHIP 100K 5% 1/16W
Note: IC4 and IC11 cannot exchange with single. When these parts
are damaged, exchange the complete mounted board.
