– 98 –
APPENDIX
No. 1
DIP-SW1
2 3 4 5 6 7 8
No. 1
DIP-SW2
2 3 4
B-3. USB Interface Model
ON ON
OFF OFF
Switch
Function ON OFF
1-1 Command emulation (Ster Line mode) Always ON
1-2 Should not be changed (Should be set to on)
1-3 Should not be changed (Should be set to on)
1-4 Sensor adjustment Invalid Valid
1-5 USB mode (See below) *1
1-6 USB mode (See below) *1
1-7 Automatic status back function *2 Invalid Valid
1-8 Should not be changed (Should be set to on)
*1 USB Mode settings are enabled only when the firmware of the USB interface board is USB 2.00 or
later.
*2 Automatic status back function is disabled when USB mode is 0.
The factory settings of DIP switch are all on.
Switch 1-5 Switch 1-6 USB Mode
ON ON Mode 0 (Printer class old)
OFF ON Mode 2 (Vendor class)
ON OFF Mode 1 (Printer class new)
OFF OFF (Reserved)
Note:
1) A STAR USB Printer Driver Set is needed for using the USB interface on
Windows 98 or 98SE. You can download the STAR USB Printer Driver
Set from the following website.
2) Download the Mode 2 (vendor class) driver set from the following website
for use.
Printer Driver URL
http://www.star-m.jp/eng/dl/dl02.htm
DIP-SW 2
Switch
Function ON OFF
2-1~2-4 Always ON Should be set to on
The factory settings of DIP switch are all on.
DIP-SW1
To Next Page
