Removal
Troubleshooting chart - see
"Standard Repairs, Trouble-
shooting" handbook.
-Removeclutch housing -
see 9.1 or11.2.
All models
•
Inspect clutch drum. There
should be no scores or signs of
excessive wear.
Important:If there are signs of
serious wear on the inside
diameter, fit a new clutch drum -
see 11.2.
- Remove the shroud -see 4.1.
- Pull off the spark plug boot.
- Unscrew the spark plug.
FS 120...350, FR 350
•
Fit locking strip (1)
0000 893 5903.
FS 400/450, FR 450
•
Fit locking strip (1)
4221 893 5900.
•
Take out screws (1).
•
Remove cover (2).
•
Remove clutch shoes with
bushings.
•
Take bushings out of the clutch
shoes.
•
Twist the clutch shoes and
detach the springs.
Important:Clutch shoes and
springs must always be replaced
in pairs.
3. CLUTCH
3.1 Removing and Installing
2
5
0
R
A
0
0
1
1
V
A
2
5
0
R
A
0
0
2
1
V
A
2
5
0
R
A
0
0
4
11
2
V
A
2
5
0
R
A
0
0
3
V
A
2
5
0
R
A
0
0
5
V
A
2
5
0
R
A
2
3
0
V
A
2
5
0
R
A
2
2
9
V
A
FS 120, 200, 300, 350, 400, 450, FR 350, 450 7
