English 22 Troubleshooting Guide
22.1 Trimmer and Battery
22 Troubleshooting Guide
Always remove the battery before carrying out any inspection, cleaning or maintenance.
Condition LEDs on
Battery
Cause Remedy
Trimmer does not
start when switched
on.
No electrical contact
between trimmer
and battery.
► Remove the battery, @ 13.2.
► Visually check the electrical contacts in the battery
compartment and on the battery.
► Reinsert the battery, @ 13.1.
1 LED flashes
green.
STIHL AR
Series: four
long beeps are
emitted (AR L -
six beeps).
Battery has low
charge.
► Charge the battery, @ 9.
1 LED glows
red.
Battery too hot / too
cold.
► Allow the battery to warm up or cool down gradually at
ambient temperatures of about 50 °F to 68 °F (10 °C to
20 °C).
4 LEDs flash
red.
STIHL
AR Series:
Additionally, a
rapid
succession of
short beeps is
emitted.
Malfunction in
battery.
► Remove the battery and reinsert it, @ 13.
► Switch on the trimmer, @ 14.1.
► If the LEDs continue to flash, do not attempt to use.
The battery has a malfunction and must be replaced.
3 LEDs glow
red.
Trimmer too hot. ► Allow the trimmer to cool down.
3 LEDs flash
red.
Malfunction in
trimmer.
► Remove the battery and reinsert it, @ 13
► Switch on the trimmer, @ 14.1.
► If the LEDs still flash, do not attempt to use.
The trimmer has a malfunction and must be checked by a
servicing dealer.

Stihl FSA 86 R Specifications

General

Type	String trimmer
Cordless	Yes
Head type	Nylon line
Handle type	D-loop handle
Product color	Black, Orange, White
Uncertainty K	2 m/s²
Sound power level	91 dB
Vibration emission	3.7 m/s²
Sound pressure level	77 dB
Cutting diameter (max)	350 mm
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Length	1720 mm
Weight	3200 g
