39MS 210, MS 230, MS 250
7.6 Ignition System Troubleshooting
Engine does not run
Master Control lever/slide control
or separate stop switch
in position "1"?
Check the spark plug:
– Smeared with oil, black?
– Sooted?
– Electrode gap correct?
– Contacts shorted?
Clean the plug, reset
or replace
Check spark plug boot:
Firmly seated on plug (leg spring)?
Leg spring hook in center of ignition lead?
Boot damaged?
If necessary, install new spark plug boot
and/or leg spring
Test ignition system with
ZAT3 or ZAT4
(use ZAT 3 as main spark gap
– see TI 32.94)
1
