69MS 210, MS 230, MS 250
12. Special Servicing Tools
No. Part Name Part No. Application Rem.
1 Locking strip 0000 893 5903 Blocking the crankshaft
2 Press sleeve 1123 893 2400 Installing oil seal(s)
3 Guide sleeve 1123 894 7700 Protects oil seal at starter side
4 Puller 5910 890 4400 Removing oil seals 1)
5 Jaws (No. 6 profile) 0000 893 3711 Removing oil seals
6 Puller 1116 893 0800 Removing flywheel
7 Crimping tool 5910 890 8210 Attaching connectors to
electrical wires
8 Assembly drift 1110 893 4700 Removing and fitting piston pin
9 Carburetor and crankcase tester 1106 850 2905 Testing engine and carburetor
for leaks
10 Nipple 0000 855 9200 Testing carburetor for leaks
11 Fuel hose 1110 141 8600 Testing carburetor for leaks
12 Vacuum pump 0000 850 3501 Testing engine for leaks
13 Sealing plate 0000 855 8106 Sealing exhaust port for
leakage test
14 Flange 1123 855 4200
15 Sleeve (4) 1123 851 8300
16 Flange 1118 850 4200 Leakage test
17 Setting gauge 1111 890 6400 Setting air gap between ignition module
and flywheel
18 Socket, DIN 3124, 13 mm 5910 893 5608 Flywheel nut
19 Socket, DIN 3124, 19 mm x12.5L 5910 893 5612 Clutch
20 Torque wrench 5910 890 0301 0.5 – 18 Nm (0.4 – 13.5 lbf.ft)
Alternative:
Torque wrench 5910 890 0302 with
optical/acoustic signal
21 Torque wrench 5910 890 0311 6 – 80 Nm (4.4 – 60 lbf.ft)
Alternative:
Torque wrench 5910 890 0312 with
optical/acoustic signal
22 Spline screw socket T 27 x 150 0812 542 2104 IS-P screws (4 mm)
Remarks:
1) Equivalent to puller 0000 890 4400, but with longer spindle 5910 890 8400.
