Stihl RE 661 User Manual

RE 661, RE 661 PLUS, RE 961 PLUS
English
64
Weight
With spray attachment and high-
pressure hose:
High-pressure hose
Sound and vibration levels
Sound pressure level L
p
to ISO 3744
(at a distance of 1 m)
Sound power level L
w
to ISO 3744
Vibration level a
hv
at the handle
according to ISO 5349
For the sound pressure level and the
sound power level, the K-factor in
accordance with Directive 2006/42/EG =
1.0 dB(A); for the vibration level, the
K-factor in accordance with
Directive 2006/42/EG = 2.0 m/s
2
.
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Pipe cleaning kit
in lengths 10 or 20 m
There is a mark (arrow) at the end of the
cleaning hose:
N Push the hose into the pipe to be
cleaned until this mark is reached –
then switch on the machine
When this mark appears as the hose is
pulled out of the pipe:
N Switch off machine
N Actuate the spray gun until the
machine has been depressurized
N Pull the hose out of the pipe
completely
The hose must never be pulled out of the
pipe when the machine is switched on.
Other special accessories
Rotary washing brush – exchangeable
brush insert.
Wash brush – for mounting on straight
or angled spray lances.
RE 661: approx. 180 kg
RE 661 PLUS:
2)
Japan only (50 Hz version)
3)
Japan only (60 Hz version)
approx. 185 kg
approx. 189 kg
2),
3)
RE 961 PLUS: approx. 189 kg
RE 661: 10 m, DN 08, steel
braided
RE 661 PLUS: 20 m, DN 08, steel
braided
RE 961 PLUS: 20 m, DN 10, steel
braided
RE 661, RE 661 PLUS: 73.8 dB(A)
RE 961 PLUS: 74.1 dB(A)
RE 661, RE 661 PLUS: 88.8 dB(A)
RE 961 PLUS: 89.1 dB(A)
RE 661, RE 661 PLUS: < 2.5 m/s
2
RE 961 PLUS: < 2.5 m/s
2
Special Accessories
669BA010 KN
