Stryker CrossFlow Service Manual

EN-15
DRAFT
1� Press to remove air from the
inow tubing� The icon indicates that
the pump is operating�
Note: This step must be performed each time
a new Inow Cassette is inserted into the
pump�
2� Once the air has been removed and tubing is
completely lled with uid, close the pinch
clamps or stopcock�
3� Open the pinch clamps or stopcock to
proceed with pump operation�
4� Press to start/stop the pump�
During a Procedure
Changing the Pressure and Flow
Note: Follow these instructions to select or change pressure and ow settings if the user preference le does
not specify these settings� Adjusting the settings will override the default and user preference le settings�
The system will select the following default settings for the following application areas:
Joint Default Settings
Knee 45mmHg
Shoulder 50mmHg
Hip 50mmHg
Small 35mmHg
Note: Default pressure settings are only suggestions, and each procedure and each patient may require
dierent parameters� Select the optimal pressure based on the patient prole, including, but not limited to,
blood pressure, height, weight, age, and tissue quality�
1� If necessary, press and to increase
or decrease the Set Pressure (adjust in
increments of 5mmHg from 15–150mmHg)
and Flow or Suction (adjust in increments of
10% from 0–100%)�
In this scenario, the pump is operating in
Inow/Outow mode� The Set Pressure is set
at 45mmHg, and the Suction is set at 50%�
Note: A green box will surround the suction/
ow value when the pump reaches the ow
limit� The pump is operating in constant ow
mode� Once the ow limit is reached, it will
operate in constant ow mode� (The pump
will attempt to operate at the set pressure
until the ow limit is reached�)
