12-8
Specifications
&
Fuse
panel
located
in
the
engine
compartment
A)
Main
fuse
Fuse
panel
Fuse
rating
Circuit
1
30A
.
ABS
unit
.
V
ehicle
dynamics
con-
trol
unit
2
25A
.
Main
fan
3
10A
.
Secondary
air
combina-
tion
valve
(turbo
models)
4
25A
.
Sub
fan
5
Empty
6
Empty
7
30A
.
Headlight
(low
beam)
8
15A
.
Headlight
(high
beam)
9
20A
.
Back-up
light
10
15A
.
Horn
1
1
25A
.
Rear
window
defogger
.
Mirror
heater
12
15A
.
Fuel
pump
13
10A
.
Automatic
transmission
control
unit
14
7.5A
.
Engine
control
unit
15
15A
.
Turn
and
hazard
warn-
ing
flasher
16
15A
.
T
ail
and
illumination
re-
lay
17
7.5A
.
Alternator
