Fuse
panel
Fuse
rating
Circuit
18 15A
. Headlight (right side)
19 15A
. Headlight (left side)
Bulb chart
Description Wattage Bulb No.
Headlight
Low beam headlight (except WRX STI) 12V-55W H11
Low beam headlight (WRX STI) 12V-35W D2S
High beam headlight 12V-60W 9005 (HB3)
Front fog light 12V-51W 9006 (HB4)
Front turn signal/Front side marker light 12V-27/8W 1157NA
Rear combination light
Rear turn signal light (4-door) 12V-21W (WY21W)
Brake/tail and rear side marker light
(4-door)
12V-21/5W 7443 (W21/5W)
Back-up light (4-door)
12V-16W 921
Rear side marker light (5-door) 12V-5W 168
Rear turn signal light (5-door) 12V-21W (WY21W)
Back-up light (5-door)
12V-21W 7440
High mount stop light (4-door) 12V-21W (P21W)
License plate light 12V-5W 168 (W5W)
Trunk room light (4-door) 12V-5W W5W
Cargo area light (5-door) 12V-5W –
Dome light 12V-8W –
Map light 12V-8W –
Specifications
12-9
