5-16 FUEL SYSTEM
FUEL TANK
DISASSEMBLY / REASSEMBLY
When disassembling or reassembling the fuel tank, refer to the construction diagram below.
Plastic tank Steel tank
K
2
1
E
D
C
B
A
0
9
8
6
5
I
H
H
J
H
H
G
F
1 Fuel hose assy (
1
)
[2
–(a) Connector (
1
)]
[2
–(b) Connector (
1
)]
[3 Clip (
4
)]
[4 Primer bulb (
1
)]
5 Tank cap (
1
)
6 Gasket (
1
)
7 Connector plug (
1
)
8 Outlet (
1
)
9 Filter (
1
)
0 O-ring (
1
)
A Fuel tank (
1
)
1 Tank cap (1)
2 Gasket (1)
3 Screw (4)
4 Gasket (4)
5 Connector plug (1)
6 Gasket (1)
7 Fuel gauge assy (1)
[8 Cover (1)]
[9 Gasket (1)]
[0 Lens (1)]
[A Gasket (1)]
[B Screw (2)]
[C Float (1)]
[D Push nut (1)]
[E Gasket (1)]
F Fuel hose assy (1)
[G Connector (1)]
[H Clip (4)]
[I Connector (1)]
[J Primer bulb (1)]
K Fuel tank (1)
1
2
–(a)
3
3
4
3
3
2
–(b)
5
7
8
9
0
6
A
3
4
7

Suzuki DF 60 Specifications

General

Cylinders	3
Steering	Remote
Starting System	Electric
Max Power Output	60 hp
Trim Method	Power Trim and Tilt
Engine Type	4-stroke
Displacement	941 cc
Fuel Delivery System	Sequential Multi Point Fuel Injection
Maximum Output	60 HP
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Recommended Fuel	Unleaded gasoline
Exhaust	Through propeller hub
Cooling System	Water-cooled
Warranty	3-year limited warranty
